MK-420C Volumetric Vertical Form Film Sealer Packaging Machine

$9,600.00$11,500.00

aterial,such as: Beans,tea,sugar,salt,fresh and dried fruit.

Clear

RELATED PRODUCTS

Application

Applied to packaging the high accuracy and easy fragile material,such as: Beans,tea,sugar,salt,fresh and dried fruit.

Features

1.New design with perfect fashion,more reasonable structure,more advanced technology..

2. Imported PLC control system,colorful touch screen,easy operation,high efficient.

3. Standard positioning with imported servo film transporting system and mark sensor,

Super excellent capability for complete machine,perfect packaging.

4.With auto warning protection function to minimize loss.

5.Various kinds of bag, it could provide the pillow bag, angle fold bag, hang hole bag,.link bag,etc.

Model

MK-420C, MK-520C

Film width

Max.420mm, Max.520mm

Bag length

80-320mm, 80-360mm

Bag width

60-200mm, 100-250mm

Diameter of film roll

Max.320mm

Packing speed

5-60bag/min

Measuring range

150-500ml, 2000ml

Film thickness

0.04-0.08mm, 0.04-0.12mm

Power

220V,50/60Hz,2KW, 220V,50/60Hz,3KW

Machine size(L*W*H)

1217*1015*1343mm, 1488*1080*1490mm

Machine weight

About 650kg, About 680kg
